Sack Pneumatic Valve Bag Filling Machine Coffee Powder Granular Filling Machine
Product description:
Vacuum type valve bag filling machine DCS-VBNP is specially designed and manufactured for superfine and nano powder with large air content and small specific gravity. Characteristics of the packaging process no dust spillover, effectively reduce the environmental pollution. Packaging process can achieve high compression ratio to fill materials, so that the shape of the finished packaging bag is full, the packaging size is reduced, and the packaging effect is particularly prominent. Representative materials such as silica fume, carbon black, silica, superconducting carbon black, powdered activated carbon, graphite and hard acid salt, etc.
Vacuum type valve bag filling machine DCS-VBNP is specially designed and manufactured for superfine and nano powder with large air content and small specific gravity. Characteristics of the packaging process no dust spillover, effectively reduce the environmental pollution.
Technical Parameters:
| Model | DCS-VBNP |
| Weight range | 1～50kg/Bag |
| Accuracy | ±0.2～0.5% |
| Packing speed | 60～200 bag/hour |
| Power | 380V 50Hz 5.5Kw |
| Air consumption | P≥0.6MPa Q≥0.1m3/min |
| Weight | 900kg |
| Size | 1600mmL × 900mmW × 1850mmH |
Product
Applicable material
About us
Wuxi Jianlong Packaging Co., Ltd. is a R & D and production enterprise specializing in solid material packaging solution. Our product portfolio includes bagging scales and feeders, open mouth bagging machines, valve bag fillers, jumbo bag filling machine, automatic packing palletizing plant, vacuum packaging equipment, robotic and conventional palletizers, stretch wrappers, conveyors, telescopic chute, flow meters, etc. Wuxi Jianlong has a group of engineers with strong technical strength and rich practical experience, which can help customers with one-stop service from solution design to product delivery, freeing workers from the heavy or unfriendly working environment, improving production efficiency, and will also create considerable economic returns for customers.
